Pulsar Symbion LRF DXR50 Multispectral Binoculars | 640×480 · sNETD <18 mK · LRF 1500 m | IP67

Pulsar · Multispectral Binocular · Thermal + 4K

Pulsar Symbion LRF DXR50
Multispectral Binocular 640×480 · LRF · IP67

Thermal 640×480 with sNETD <18 mK, 4K digital channel, laser rangefinder 1,500 m and multispectral fusion – all in one IP67 magnesium housing.

Multispectral system – thermal, 4K digital and LRF in one housing

The Pulsar Symbion LRF DXR50 combines three powerful observation systems in a robust magnesium housing: a 640×480 thermal sensor with an outstanding system NETD of <18 mK (better than many higher-resolution devices), a 4K CMOS day camera (3,840×2,160) with 6.5–26× digital zoom and a Class 1 laser rangefinder (905 nm, up to 1,500 m, ±1 m). In multispectral fusion mode, both image signals are overlaid in real time – for maximum situational awareness by day, at dusk and at night.

4K digital channel with fusion and PIP mode – day and night

The 4K CMOS digital sensor (3,840×2,160, 50 mm, F/1.8) delivers detail-rich colour images at 6.5–26× magnification and a field of view of 5.8° (10.2 m at 100 m). The integrated 850 nm IR illuminator extends operational use into the night. In fusion mode, the thermal and colour images are overlaid in real time; picture-in-picture mode (PIP) shows both channels simultaneously. All recordings – photo and video with audio – are stored on the 64 GB internal storage and can be managed via the Stream Vision 2 app on a smartphone.

IP67 magnesium housing, LRF 1,500 m and up to 10 h runtime

The magnesium alloy housing is fully dustproof and waterproof to IP67 (short-term submersion up to 1 m). The integrated 905 nm laser rangefinder measures up to 1,500 m at the press of a button with ±1 m accuracy. Two included APS5 battery packs guarantee up to 10 hours of operation – more than the top model DXT50. Dual-band Wi-Fi (2.4 + 5 GHz) and Bluetooth connect the device to the Stream Vision 2 app for livestream, remote control and firmware updates. The 1/4″ tripod thread enables stable long-term use on tripods.

Key features – Pulsar Symbion LRF DXR50

• 🔬 Thermal sensor 640×480, 12 μm, F/1.0 (50 mm germanium), sNETD <18 mK
• 🎥 4K CMOS day camera 3,840×2,160, F/1.8 (50 mm), 6.5–26×
• 📡 Detection range 2,300 m · Thermal 4×–32×, FOV 8.8°
• 📏 Laser rangefinder 905 nm: up to 1,500 m, ±1 m
• 🔄 Multispectral fusion + picture-in-picture (PIP), 9 colour palettes, EIS
• 💡 850 nm IR illuminator (integrated)
• 🖥️ Dual-AMOLED display 1,920×1,080 px
• 💾 64 GB internal storage · Wi-Fi dual-band · Bluetooth · Stream Vision 2
• 💧 IP67 · Magnesium alloy · −25 °C to +50 °C · 1/4″ tripod
• 🔋 2× APS5 (included), up to 10 h · USB-C (5V/9V) · 1,000 g

For hunters, wildlife observers and security professionals

The Symbion LRF DXR50 is the ideal all-round binocular for demanding missions: superior thermal sensitivity (sNETD <18 mK), long battery life and the robust IP67 housing make it a reliable companion for hunting, wildlife observation, security operations and expeditions – in any weather and at any time of day or night.
